The insulation of the new design chimneys is 25 mm thick, but retains the properties of the 50 mm thick insulation material. Thanks to the smaller outer diameter, the chimneys look more aesthetically attractive, easier to assemble the elements, each connection has thermal compensation. The insulation is crushed and blown into the chimneys of the new design. Thanks to this new technology, the insulation density is higher than 180 kg / m³. The inner tube is made of stainless steel EN 1.4404, the outer - 1.4301 type steel. Operating temperature <= 450 ° C. The system is resistant to soot ignition, suitable for operation in wet conditions. Suitable for systems using gaseous, liquid (excluding sulfur content> = 0.2% by weight) or solid fuels (excluding coal and peat).

Height, mm - 160

Width, mm - 200

Depth, mm - 200

Made of - 316 stainless steel

Chimney diameter, mm - 150/200

Wall thickness, mm - 0.5

Insulation thickness, mm - 25

Maximum temperature, C - 450
