EBERLE DTR-E 3102 A wall mounted differential thermostat for guttering and outside surface heating.

Article: 1069104

Category: Floor heating automatics and components

Unit: pc.

Barcode: 4017254109171

52,90 €/pc.

Available in stores:

Mūkusalas iela 93

Ata iela 5a

Description
Additional info

This differential room thermostat contains two 16A / 230V contacts connected in series. The first one (blue scale) is for switching off (+20...-20°C) - when the temperature drops below a set value, the contact switches off. The second one (red scale) is for switching on (+25...0°C) – when there is a drop under a set value, the contact switches on. A temperature interval “From-To” (e.g. from -10°C do +5°C) can be set for which the connected appliance (e.g. heating cable) will be powered. The thermostat can also be placed in outdoor areas (e.g. on a facade). NOTE: The thermostat measures only temperature - it doesn´t monitor the presence of water, snow or ice. In anti-ice protection applications (the protection of roof gutters and downpipes, drives, pavements, steps, etc.) it is necessary to supervise the operation of the system in order to achieve economical operation.

Weight	0.08 kg
Dimensions	0 x 0 x 0 cm
Brand	EBERLE

EBERLE DTR-E 3102 A wall mounted differential thermostat for guttering and outside surface heating.
